Pneumatic high-pressure union ball valve

Overview:

The pneumatic high-pressure ball valve is composed of a pneumatic actuator and a high-pressure ball valve. The 90-degree rotation of the pneumatic actuator drives the rotation of the valve ball, thereby achieving the opening and closing of the medium. The valve body is processed by forging technology, which can enhance the material strength and avoid defects such as pores and sand holes in castings. It adopts double union connection and can be quickly assembled without the use of special tools. It has the advantages of compact structure, wear resistance, easy disassembly, convenient inspection and maintenance, and is widely used in the petroleum, chemical, natural gas, power and other industries.

Technical parameters:

◆ Diameter: DN15-DN100

◆ Pressure range: PN320, PN500

◆ Control gas: Neutral gas, air

◆ Air source pressure: 4bar-8bar

◆ Valve body material: WCB, CF8, CF8M, CF3M

◆ Sealing material: RPTFE, PEEK

◆ Medium temperature: -20℃ to + 180℃

◆ Connection methods: Double union, internal thread, flange

◆ Applicable media: water, liquids, gases, oils, acidic and alkaline corrosive liquids, etc

◆ Optional accessories: Single-acting cylinder, double-acting cylinder, position feedback, solenoid valve, single coupling, handwheel, etc
